241/A ECOdrive (EC0241A2) eldoLED Programmable Constant Current LED Driver - 20W 0-10V Dim 220-240V

(No reviews yet) Write a Review
SKU:
BS46-EC0241A2
MPN:
EC0241A2
Availability:
In Stock - unless otherwise indicated by stock status below
Shipping:
Calculated at Checkout
Bulk Pricing:
Buy in bulk and save

Bulk discount rates

Below are the available bulk discount rates for each individual item when you purchase a certain amount

  • Buy 10 or above and get 3% off
FREE PROGRAMMING
  • 241/A ECOdrive (EC0241A2) eldoLED Programmable Constant Current LED Driver - 20W 0-10V Dim 220-240V
  • 241/A ECOdrive (EC0241A2) eldoLED - Specifications
  • 241/A ECOdrive (EC0241A2) eldoLED - Control
  • 241/A ECOdrive (EC0241A2) eldoLED - Wiring
  • 241/A ECOdrive (EC0241A2) eldoLED - Dimensions
  • 241/A ECOdrive (EC0241A2) eldoLED - Metal Case Plastic Terminal Cover
  • eldoLED Form Factor Overview
  • 241/A ECOdrive (EC0241A2) eldoLED - - Program Code
MSRP: $60.00
Now: $39.95
Was: $60.00
— You save $20.05

Description


ECOdrive 241/A Programmable Constant Current LED Driver, 20W Max Power Output, 220-240V Input, Programmable Fixed Current Output 150-1400mA, Single 2-40V Output, Analog 0-10V Dimming 1%-100%, Side Feed w/ Plastic Cover Feet Mounting

eldoLED ECOdrive 241/A 20W Constant Current Analog (0-10V) Dimmable LED Driver 220-240V

ECOdrive, 20W, 0-10V, 1 control channel, constant current, 1 x 40V output, side feed square metal case/plastic lead cover

Programmable Options:

  • Output Current: 150-1050mA in 1mA increments
  • Dimming Curve: LIN linear, LOG logarithmic (factory default), SNL soft linear, SQU square
  • Minimum Dimming Level: 1% (factory default) in 0.1% increments

If you do not enter the programmable output settings as outlined above ADD TO CART, we will contact you after placing the order to get the output settings (from sticker on the driver for existing applications or custom settings for new applications) so we can program unit to this output specification. We are not able to ship with out programming.

For example 600MA LIN is what we will need to program your driver prior to shipping.


Common Custom Program Codes

Product Catalog No. CICode UPC   Product Catalog Number CICode UPC
EC0241A2 1050MA LOG *2843XE 197589403091   EC0241A2 375MA LOG *2541WA 193047453264
EC0241A2 150MA LOG *2583S2 193048059359   EC0241A2 400MA LOG *278X80 196183018694
EC0241A2 175MA LOG *293R5L 198935501164   EC0241A2 440MA LOG *252STL 193047148733
EC0241A2 180MA LOG *282HC2 197589022841   EC0241A2 450MA LOG *2583S4 193048059366
EC0241A2 200MA LIN *2671FU 194994183068   EC0241A2 500MA LIN *251GXM 191848632314
EC0241A2 200MA LOG *256YGS 193047914222   EC0241A2 500MA LOG *2522EL 191848751886
EC0241A2 230MA LOG *273N8V 194995785124   EC0241A2 580MA LOG *26310H 193048581737
EC0241A2 250MA LIN *2581UL 193048045079   EC0241A2 600MA LOG *257FJT 193047992824
EC0241A2 250MA LOG *2577M9 193047971072   EC0241A2 630MA LOG *268TK7 194994618256
EC0241A2 260MA LOG *256L94 193047892995   EC0241A2 650MA LOG *288T79 197590499014
EC0241A2 300MA LIN *2583YX 193048061345   EC0241A2 700MA LIN *252FCJ 193047044424
EC0241A2 300MA LOG *252S69 193047143356   EC0241A2 700MA LOG *251GXP 191848632345
EC0241A2 325MA LOG *284LKJ 197589517248   EC0241A2 800MA LOG *27939V 196183057747
EC0241A2 350MA LIN *251GXK 191848632307   EC0241A2 900MA LIN *252CC3 193047024341
EC0241A2 350MA LOG *261A5U 191723397482   EC0241A2 900MA LOG *267PSS 194994348931
View AllClose

Additional Information

Our Part No.:
BS46-EC0241A2
Manufacturer Part No.:
EC0241A2
Brand:
Acuity eldoLED ECOdrive
Fixture Type:
LED
Driver Type:
Constant-Current-Programmable
Input Voltage:
220-240V
Max Output Power:
20W
Max Output Current:
1050mA
Max Output Voltage:
40V
Dimming:
Analog (0-10V), LEDcode
Product Data Sheet:
See PDF Link Provided
Location Rating:
Dry/Damp
Dimensions:
6.3" L x 1.6" W x 1.2" H
UL Class:
Class 2
Features:
Rectangular Case, Side Terminal Connector with Plastic Cover
Alternative Keywords:
EC0241A1, ECO241A2, ECO241A1
Warranty:
Manufacturer's
Case Size:
10
