261/B ECOdrive (EC0261B2) eldoLED Programmable Constant Current LED Driver - 20W 0-10V Dimming

(No reviews yet) Write a Review
SKU:
BS46-EC0261B2
MPN:
EC0261B2
Availability:
In Stock unless otherwise indicated below
Shipping:
Calculated at Checkout
Bulk Pricing:
Buy in bulk and save

Bulk discount rates

Below are the available bulk discount rates for each individual item when you purchase a certain amount

  • Buy 10 or above and get 5% off
  • 261/B ECOdrive (EC0261B2) eldoLED Programmable Constant Current LED Driver - 20W 0-10V Dimming
  • 261/B ECOdrive (EC0261B2) eldoLED - Output Specifications
  • 261/B ECOdrive (EC0261B2) eldoLED - Control
  • 261/B ECOdrive (EC0261B2) eldoLED - Terminal Connections
  • 261/B ECOdrive (EC0261B2) eldoLED - Dimensions
  • eldoLED Form Factors
  • 261/B ECOdrive (EC0261B2) eldoLED - Program Code
MSRP: $96.00
Now: $79.95
Was: $96.00
— You save $16.05

Description


ECOdrive 261/B Programmable Constant Current LED Driver, 20W Max Power Output, Universal 120-277V Input, Programmable Fixed Current Output 150-1400mA, 2-55V Output, Analog 0-10V Dimming 1%-100%, Bottom Exit Stud Mounting

eldoLED ECOdrive 261/B 20W LED Driver

ECOdrive, 20W, 120-277V, 0-10V, 1 control channel, constant current, 1 x 55V output, bottom feed, metal square

Programmable Options:

  • Output Current: 150-1400mA in 1mA increments
  • Dimming Curve: LIN linear, LOG logarithmic, SNL soft linear, SQU square
  • Minimum Dimming Level: 1% (factory default) in 0.1% increments

If you do not enter the programmable output settings as outlined above ADD TO CART, we will contact you after placing the order to get the output settings (from sticker on the driver for existing applications or custom settings for new applications) so we can program unit to this output specification. We are not able to ship with out programming.

For example 600MA LIN is what we will need to program your driver prior to shipping.


Common Program Codes

Product Catalog Number CICode UPC   Product Catalog Number CICode UPC
EC0261B2 225MA LOG *281TFK 196183701138   EC0261B2-CA24 400MA LIN *254MY1 193047579957
EC0261B2 300MA LIN *2584G6 193048064506   EC0261B2-CA24 400MA LIN 10.0MIN *273PJN 194995794836
EC0261B2 350MA LIN *252TYG 193047164153   EC0261B2-CA24 400MA LOG *274GSK 194995962273
EC0261B2 350MA LOG *249VN0 191848045619   EC0261B2-CA24 500MA LIN *2541X1 193047453486
EC0261B2 360MA LOG *281TFL 196183701091   EC0261B2-CA24 700MA LIN *2549Y7 193047514361
EC0261B2 400MA LIN *252U0C 193047164399   EC0261B2-ES16 175MA LIN *25506H 193047652124
EC0261B2 475MA LIN *252U0K 193047164474   EC0261B2-ES16 175MA LIN 10.0MIN *25506K 193047652148
EC0261B2 500MA LIN *282YP0 197589137576   EC0261B2-ES16 225MA LIN *273PJM 194995794874
EC0261B2 500MA LOG *2600ES 193048273823   EC0261B2-ES16 230MA LIN *2571MR 193047926362
EC0261B2 560MA LOG *283W12 197589349795   EC0261B2-ES16 230MA LIN 10.0MIN *2571MN 193047926348
EC0261B2 700MA LIN *2581TC 193048044720   EC0261B2-ES16 250MA LIN *273PHS 194995794645
EC0261B2 700MA LOG *254SPV 193047608503   EC0261B2-ES16 250MA LIN 10.0MIN *273PJ1 194995794690
EC0261B2 700MA LOG J40 *2633KJ 193048602173   EC0261B2-ES16 260MA LIN *25694C 193047861212
EC0261B2 840MA LOG *283W13 197589349818   EC0261B2-ES16 260MA LIN 10.0MIN *2569X0 193047867436
EC0261B2 900MA LIN *267KT9 194994315414   EC0261B2-ES16 265MA LIN *2569X5 193047867504
EC0261B1 425MA LOG 85NTC *262FJW 191723627855   EC0261B2-ES16 265MA LIN 10.0MIN *2569X3 193047867511
EC0261B2-CA24 250MA LIN *2548YS 193047506793   EC0261B2-ES16 340MA LIN *265SRJ 193048869217
EC0261B2-CA24 275MA LIN *273PJ7 194995794768   EC0261B2-ES16 350MA LIN *265SGS 193048867008
EC0261B2-CA24 275MA LIN 10.0MIN *273PJA 194995794812   EC0261B2-ES16 360MA LIN *2571MT 193047926386
EC0261B2-CA24 300MA LIN *253S4V 193047414661   EC0261B2-ES16 360MA LIN 10.0MIN *2571MW 193047926423
EC0261B2-CA24 300MA LOG *273PJ3 194995794713   EC0261B2-ES16 400MA LIN *273PJV 194995794911
EC0261B2-CA24 320MA LOG *291Y89 198934327444   EC0261B2-ES16 400MA LIN 10.0MIN *273PLL 194995795420
EC0261B2-CA24 325MA LIN *267GE2 194994287445   EC0261B2-ES16 475MA LIN *273PHX 194995794652
EC0261B2-CA24 350MA LIN *254L1P 193047564489   EC0261B2-ES16 475MA LIN 10.0MIN *273PLS 194995795451
EC0261B2-CA24 350MA LIN 10.0MIN *261531 193048412741   EC0261B2-ES16 560MA LIN *283W0L 197589349641
EC0261B2-CA24 350MA LIN 10.0MIN *273S53 194995807512   EC0261B2-ES16 840MA LIN *283W0P 197589349689
EC0261B2-CA24 350MA LOG *2501Y1 191848158821   EC0261B2-VLC-SF185-ES16 400MA LIN *2855RR 197589651898
EC0261B2-CA24 360MA LIN *274WWG 196182063367   EC0261B1-CA24 350MA LIN 10.0MIN *268J25 194994547624
EC0261B2-CA24 375MA LIN *273PJH 194995794829
EC0261B2-CA24 375MA LIN 10.0MIN *273PJL 194995794850
View AllClose

Additional Information

Our Part No.:
BS46-EC0261B2
Manufacturer Part No.:
EC0261B2
Brand:
Acuity eldoLED ECOdrive
Fixture Type:
LED
Driver Type:
Constant-Current-Programmable
Input Voltage:
120-277V (Universal)
Max Output Power:
20W
Max Output Current:
1400mA
Max Output Voltage:
55V
Dimming:
Analog (0-10V)
Product Data Sheet:
See PDF Link Provided
Location Rating:
Dry/Damp
Dimensions:
5.12" L x 2.79" W x 1.35" H
UL Class:
Class 2
Features:
Square Metal Case, Bottom Feed, Stud Mount
Alternative Keywords:
EC0261B1, EC0261B
Warranty:
Manufacturer's
Case Size:
10
