561/S ECOdrive (EC0561S3) eldoLED Programmable Constant Current LED Driver - 50W 0-10V Dimming

(No reviews yet) Write a Review
SKU:
BS46-EC0561/S
MPN:
EC0561S3
Availability:
In Stock - unless otherwise indicated by stock status below
Shipping:
Calculated at Checkout
Bulk Pricing:
Buy in bulk and save

Bulk discount rates

Below are the available bulk discount rates for each individual item when you purchase a certain amount

  • Buy 10 or above and get 5% off
  • 561/S ECOdrive (EC0561S3) eldoLED Programmable Constant Current LED Driver - 50W 0-10V Dimming
  • 561/S ECOdrive (EC0561S3) eldoLED - Output Specifications
  • 561/S ECOdrive (EC0561S3) eldoLED - Control
  • 561/S ECOdrive (EC0561S3) eldoLED - Terminal Connections
  • 561/S ECOdrive (EC0561S3) eldoLED - Dimensions
  • eldoLED Form Factor
  • eldoLED ECOdrive 561/S - Program Code
MSRP: $120.00
Now: $89.95
Was: $120.00
— You save $30.05

Description


ECOdrive 561/S Constant Current LED Driver, 50W Max Output Power, Universal 120-277V Input, Programmable Fixed Current Output 150-1400mA, Single 2-55V Output, Analog 0-10V Dimming 1%-100%, Side Feed

eldoLED ECOdrive 561/S 50W LED Driver

ECOdrive, 50W, 120-277V, 0-10V, 1 control channel, constant current, 1x 55V output, side feed, metal square

Programmable Options:

  • Output Current: 150-1400mA in 1mA increments
  • Dimming Curve: LIN linear, LOG logarithmic, SNL soft linear, SQU square
  • Minimum Dimming Level: 1% (factory default) in 0.1% increments

If you do not enter the programmable output settings as outlined above ADD TO CART, we will contact you after placing the order to get the output settings (from sticker on the driver for existing applications or custom settings for new applications) so we can program unit to this output specification. We are not able to ship with out programming.

For example 600MA LIN is what we will need to program your driver prior to shipping.


Common Custom Programming Codes

Product Catalog Number CICode UPC   Product Catalog Number CICode UPC
EC0561S3 150MA LIN *291T25 198934279552   EC0561S3 860MA LIN *253YSE 193047436946
EC0561S3 175MA LIN *289C4Y 197590641888   EC0561S3 875MA LOG *285E7W 197589699401
EC0561S3 350MA LIN *269G1M 194994777182   EC0561S3 900MA LOG *2565VW 193047837293
EC0561S3 350MA LIN 1.3MIN *2537VW 193047330114   EC0561S2 900MA LIN *230FNR 888791737349
EC0561S3 350MA LOG *261G7Y 191723438307   EC0561S2 900MA LIN 10.0MIN *238J17 889804911275
EC0561S3 375MA LIN *271U6G 194995351022   EC0561S3 935MA LIN *254SR7 193047608602
EC0561S3 400MA LIN 10.0MIN *254RAC 193047600057   EC0561S3 940MA LIN *254KG2 193047559447
EC0561S3 450MA LIN *258SJG 193048136883   EC0561S2 950MA LIN *231YCP 745971256222
EC0561S3 500MA LIN *25407H 193047440332   EC0561S2 950MA LIN 10.0MIN *237V3M 889804824872
EC0561S3 500MA LOG *258NRX 193048122336   EC0561S3 960MA LIN *291F9P 198934182029
EC0561S2 525MA LIN *232A82 745971279030   EC0561S3 960MA LOG *291F7T 198934181428
EC0561S2 525MA LIN 10.0MIN *237V37 889804824759   EC0561S3 965MA LIN *254W64 193047629980
EC0561S3 550MA LIN *278P7P 196182961892   EC0561S3 1000MA LIN *253YRW 193047436854
EC0561S3 600MA LIN *289SRP 197590755615   EC0561S3 1000MA LOG *2694Y2 194994703754
EC0561S3 610MA LIN 10.0MIN *275NP0 196182238956   EC0561S3 1020MA LIN *254KFH 193047559300
EC0561S3 630MA LIN *259L6S 193048248838   EC0561S3 1025MA LIN *253YRY 193047436861
EC0561S3 635MA LIN *2968S9 199871187832   EC0561S3 1050MA LIN *253H04 193047394215
EC0561S3 635MA LIN 10.0MIN *2630MS 193048578904   EC0561S3 1050MA LOG *253HUX 193047402446
EC0561S3 650MA LIN *2804LV 196183308061   EC0561S3 1060MA LIN *254SR8 193047608633
EC0561S3 650MA LIN 10.0MIN *2581UJ 193048045055   EC0561S3 1090MA LIN *254KFM 193047559362
EC0561S3 675MA LIN *252M2T 193047099127   EC0561S3 1120MA LOG *291F7U 198934181411
EC0561S3 675MA LIN 10.0MIN *253CLE 193047364126   EC0561S3 1130MA LIN *2802ST 196183294517
EC0561S3 690MA LIN *291F2P 198934179883   EC0561S3 1130MA LIN 10.0MIN *2802SU 196183294524
EC0561S3 690MA LOG *291F1U 198934179630   EC0561S3 1150MA LIN *253YS3 193047436908
EC0561S3 700MA LIN *254KFX 193047559409   EC0561S3 1175MA LIN *254KFP 193047559355
EC0561S3 700MA LOG *253S3K 193047414296   EC0561S3 1180MA LIN *254SRC 193047608626
EC0561S2 725MA LOG *231NCL 820476991301   EC0561S3 1200MA LOG *254AP8 193047520492
EC0561S2 725MA LOG 10.0MIN *237V3C 889804824797   EC0561S3 1215MA LIN *253YS4 193047436922
EC0561S3 735MA LIN 10.0MIN *287AU2 197590161768   EC0561S3 1225MA LOG *275TF3 196182268786
EC0561S3 760MA LIN *254SPX 193047608541   EC0561S3 1250MA LIN *270K1W 194995042692
EC0561S3 760MA LOG *291F7N 198934181367   EC0561S3 1260MA LIN *259L4S 193048248814
EC0561S3 775MA LIN 10.0MIN *2870VP 197590088805   EC0561S3 1300MA LIN *2537V4 193047329873
EC0561S2 775MA LIN *238J0X 889804911183   EC0561S3 1300MA LOG *2605VY 193048317602
EC0561S3 780MA LIN *254KG0 193047559423   EC0561S3 1320MA LIN *253YS8 193047436991
EC0561S3 790MA LIN *259L5S 193048248845   EC0561S3 1340MA LIN *253YSA 193047436939
EC0561S3 800MA LIN *280PM9 196183444363   EC0561S3 1360MA LIN *254KFT 193047559317
EC0561S3 815MA LIN *254SR0 193047608534   EC0561S3 1400MA LIN *2560NK 193047796583
EC0561S3 840MA LIN *291F9M 198934181992   EC0561S3 1400MA LOG *26224P 193048491036
EC0561S3 840MA LOG *291F7J 198934181374
EC0561S2 850MA LIN *231YCE 745971256109
EC0561S2 850MA LIN 10.0MIN *237V3G 889804824827



View AllClose

Additional Information

Our Part No.:
BS46-EC0561/S
Manufacturer Part No.:
EC0561S3
Brand:
Acuity eldoLED ECOdrive
Fixture Type:
LED
Driver Type:
Constant-Current-Programmable
Input Voltage:
120-277V (Universal)
Max Output Power:
50W
Max Output Current:
1400mA
Output Current Programmable Range:
150-1400mA
Max Output Voltage:
55V
Dimming:
Analog (0-10V)
Product Data Sheet:
See PDF Link Provided
Location Rating:
Dry/Damp
Dimensions:
5.16" L x 3.02" W x 1.2" H
UL Class:
Class 2
Features:
Side Feed, Feet Mount
Alternative Keywords:
EC0561S2, EC0561S1, EC0561S
Warranty:
Manufacturer's
Case Size:
10
