563/S SOLOdrive (SL0563S4) eldoLED Programmable Constant Current LED Driver - 50W DALI Dimming

(No reviews yet) Write a Review
SKU:
BS46-SL563S
MPN:
SL0563S4
Availability:
In Stock - unless otherwise indicated by stock status below
Shipping:
Calculated at Checkout
Bulk Pricing:
Buy in bulk and save

Bulk discount rates

Below are the available bulk discount rates for each individual item when you purchase a certain amount

  • Buy 10 or above and get 5% off
  • 563/S SOLOdrive (SL0563S4) eldoLED Programmable Constant Current LED Driver - 50W DALI Dimming
  • 563/S SOLOdrive (SL0563S4) eldoLED - Output Specifications
  • 563/S SOLOdrive (SL0563S4) eldoLED - Control
  • 563/S SOLOdrive (SL0563S4) eldoLED - Terminal Connections
  • 563/S SOLOdrive (SL0563S4) eldoLED - Dimensions
  • eldoLED Form Factor Overview
  • 563/S SOLOdrive (SL0563S4) eldoLED - Program Code
MSRP: $84.00
Now: $69.95
Was: $84.00
— You save $14.05

Description


SOLOdrive 563/S Programmable Constant Current LED Driver, 50W Max Power Output, Universal 120-277V Input, Programmable Fixed Current Output 150-1400mA, 1-55V Output, DALI-2 Dimming 0.1%-100% Dim-to-Dark, Side Exit Stud Mounting

eldoLED SOLOdrive 563/S 50W LED Driver

SOLOdrive, 50W, DALI, 1 control channel, constant current, 1 x 55V output, side feed, square metal case/plastic lead cover

Programmable Options:

  • Output Current: 150-1400mA in 1mA increments
  • Dimming Curve: LIN linear, LOG logarithmic (factory default)
  • Minimum Dimming Level: 0.1% (factory default) in 0.1% increments

If you do not enter the programmable output settings as outlined above ADD TO CART, we will contact you after placing the order to get the output settings (from sticker on the driver for existing applications or custom settings for new applications) so we can program unit to this output specification. We are not able to ship with out programming.

For example 600MA LIN is what we will need to program your driver prior to shipping.

Common Custom Program Settings
Product Catalog Number CICode UPC   Product Catalog Number CICode UPC
SL0563S4 150MA LOG *282GFT 197589015393   SL0563S4 900MA LOG *2768NK 196182378140
SL0563S4 180MA LOG *28991H 197590623136   SL0563S4 930MA LOG *28487N 197589434248
SL0563S3 250MA LOG *270JE3 194995037070   SL0563S4 940MA LOG *283V2M 197589341720
SL0563S3 300MA LOG *264043 193048675221   SL0563S4 960MA LOG *291F9E 198934181923
SL0563S4 350MA LOG *26974X 194994720881   SL0563S4 970MA LOG *284C6E 197589457575
SL0563S4 350MA LOG 50V *275J64 196182203220   SL0563S4 975MA LOG *2823N2 196183771919
SL0563S4 450MA LOG *276EW2 196182411144   SL0563S4 1000MA LOG *272TSW 194995587346
SL0563S4 475MA LOG *29055S 197590860111   SL0563S4 1050MA LOG *275R03 196182249389
SL0563S3 500MA LOG *258SJ9 193048136852   SL0563S4 1090MA LOG *28487M 197589434255
SL0563S4 525MA LOG *2823N0 196183771902   SL0563S4 1110MA LOG *283V2N 197589341737
SL0563S3 550MA LOG *252WUT 193047203210   SL0563S4 1120MA LOG *291F9H 198934181978
SL0563S4 690MA LOG *288YKF 197590543137   SL0563S4 1130MA LOG *2802T1 196183294586
SL0563S4 700MA LOG *276EW8 196182411199   SL0563S4 1140MA LOG *283V2U 197589341805
SL0563S4 710MA LOG *28991F 197590623112   SL0563S4 1260MA LOG *276TCS 196182505560
SL0563S4 735MA LOG *28991L 197590623143   SL0563S4 1280MA LOG *283V2X 197589341836
SL0563S4 760MA LOG *291F97 198934181879   SL0563S4 1300MA LIN *278M2C 196182944345
SL0563S4 830MA LOG *28487P 197589434279   SL0563S4 1300MA LOG *276TCT 196182505577
SL0563S4 840MA LOG *291F2F 198934179814   SL0563S4 1400MA LOG *275E1G 196182170911
SL0563S4 875MA LOG *277XY5 196182787935
View AllClose

Additional Information

Our Part No.:
BS46-SL563S
Manufacturer Part No.:
SL0563S4
Brand:
Acuity eldoLED SOLOdrive
Fixture Type:
LED
Driver Type:
Constant-Current-Programmable
Input Voltage:
120-277V (Universal)
Max Output Power:
50W
Max Output Current:
1400mA
Output Current Programmable Range:
150-1400mA
Max Output Voltage:
55V
Dimming:
DALI
Product Data Sheet:
See PDF Link Provided
Location Rating:
Dry/Damp
Dimensions:
5.16" L x 3.02" W x 1.2" H
UL Class:
Class 2
Features:
Compact Case, Side Exit Stud Mounting
Alternative Keywords:
SL0563S3, SL0563S2, SL0563S1, SL0563S
Warranty:
Manufacturer's
Case Size:
10
