eldoLED

761/L SOLOdrive (SL0761L2) eldoLED Programmable Constant Current LED Driver - 75W 0-10V Dimming

(No reviews yet) Write a Review
SKU:
BS46-SOLO761/L
MPN:
SL0761L2
Availability:
In Stock - unless otherwise indicated by stock status below
Shipping:
Calculated at Checkout
Bulk Pricing:
Buy in bulk and save

Bulk discount rates

Below are the available bulk discount rates for each individual item when you purchase a certain amount

  • Buy 10 or above and get 5% off
  • 761/L SOLOdrive (SL0761L2) eldoLED Programmable Constant Current LED Driver - 75W 0-10V Dimming
  • 761/L SOLOdrive (SL0761L2) eldoLED - Output Specifications
  • 761/L SOLOdrive (SL0761L2) eldoLED - Control
  • 761/L SOLOdrive (SL0761L2) eldoLED - Dimming Curves
  • 761/L SOLOdrive (SL0761L2) eldoLED - Terminal Connections
  • 761/L SOLOdrive (SL0761L2) eldoLED - Dimensions
  • eldoLED Form Factor Overview
  • 761/L SOLOdrive (SL0761L2) eldoLED - Program Code
MSRP: $112.00
Now: $68.95
Was: $89.95
— You save $43.05

Description


SOLOdrive 761/L Programmable Constant Current LED Driver, 75W Max Power Output, Universal 120-277V Input, Programmable Fixed Current Output 150-1400mA, 2-55V Output, Analog 0-10V Dimming 0.1%-100% Dim-to-Dark

eldoLED SOLOdrive 761/L 75W LED Driver

SOLOdrive AC, 75W, 0-10V, 1 control channel, constant current, 2x 55V output, side feed, long metal

Programmable Options:

  • Output Current: 150-1400mA in 1mA increments
  • Dimming Curve: LIN linear, LOG logarithmic, SNL soft linear, SQU square
  • Minimum Dimming Level: 0.1% (factory default) in 0.1% increments

If you do not enter the programmable output settings as outlined above ADD TO CART, we will contact you after placing the order to get the output settings (from sticker on the driver for existing applications or custom settings for new applications) so we can program unit to this output specification. We are not able to ship with out programming.

For example 600MA LIN is what we will need to program your driver prior to shipping.

Common Custom Program Codes
Product Catalog Number CICode UPC   Product Catalog Number CICode UPC   Product Catalog Number CICode UPC
SL0761L2 1015MA LIN 1.0MIN *27676E 196182366956   SL0761L2 725MA LIN *2582K8 193048050288   SL0761L2 MCUR LIN CH1-425MA CH2-700MA *251JNT 191848651162
SL0761L2 1100MA LIN 1.0MIN *266XYY 194994162711   SL0761L2 725MA LIN 1.0MIN *2582L8 193048050578   SL0761L2 MCUR LIN CH1-425MA CH2-700MA 1.0MIN *251JUM 191848652572
SL0761L2 1200MA LIN *2551MJ 193047663052   SL0761L2 725MA LOG *2582KW 193048050448   SL0761L2 MCUR LIN CH1-575MA CH2-700MA *251JNX 191848651186
SL0761L2 1200MA LIN 1.0MIN *270TV4 194995106677   SL0761L2 725MA LOG 1.0MIN *2582LG 193048050622   SL0761L2 MCUR LIN CH1-575MA CH2-700MA 1.0MIN *251JUX 191848652657
SL0761L2 1260MA LIN *2588V5 193048097917   SL0761L2 750MA LIN *2582LN 193048050707   SL0761L2 MCUR LIN CH1-650MA CH2-700MA *270R7Y 194995085484
SL0761L2 1400MA LOG *266LE6 194994072935   SL0761L2 750MA LIN 1.0MIN *2582LV 193048050776   SL0761L2 MCUR LIN CH1-650MA CH2-700MA 1.0MIN *270R4W 194995084654
SL0761L2 1400MA LOG 0.6MIN *26527L 193048790627   SL0761L2 750MA LIN 10.0MIN *2636KA 193048626483   SL0761L2 MCUR LIN CH1-650MA CH2-725MA *270R80 194995085491
SL0761L2 175MA LIN 1.0MIN *269AVN 194994751533   SL0761L2 750MA LOG *2582LU 193048050745   SL0761L2 MCUR LIN CH1-650MA CH2-725MA 1.0MIN *270R51 194995084708
SL0761L2 200MA LIN 1.0MIN *26964U 194994713074   SL0761L2 750MA LOG 1.0MIN *2582M0 193048050790   SL0761L2 MCUR LIN CH1-650MA CH2-750MA *270R83 194995085514
SL0761L2 215MA LIN 1.0MIN *2696J6 194994715900   SL0761L2 775MA LIN 1.0MIN *274U5N 196182041457   SL0761L2 MCUR LIN CH1-650MA CH2-750MA 1.0MIN *270R7H 194995085361
SL0761L2 225MA LOG 1.0MIN *269WSM 194994891062   SL0761L2 800MA LIN *257MSU 193048015638   SL0761L2 MCUR LIN CH1-675MA CH2-875MA 1.0MIN *278WLA 196183013170
SL0761L2 325MA LIN 1.0MIN *2696J9 194994715917   SL0761L2 800MA LOG 1.0MIN *267YTJ 194994416241   SL0761L2 MCUR LIN CH1-700MA CH2-425MA *251JP3 191848651254
SL0761L2 350MA LOG *264E2E 191848088449   SL0761L2 825MA LIN 1.0MIN *26705M 194994172260   SL0761L2 MCUR LIN CH1-700MA CH2-425MA 1.0MIN *251JV0 191848652664
SL0761L2 425MA LIN 1.0MIN *272S5N 194995575343   SL0761L2 825MA LOG 1.0MIN *267YJR 194994414001   SL0761L2 MCUR LIN CH1-700MA CH2-575MA *251JP4 191848651247
SL0761L2 425MA LOG 1.0MIN *269U3H 194994868750   SL0761L2 875MA LOG 1.0MIN *2704YK 194994945918   SL0761L2 MCUR LIN CH1-700MA CH2-575MA 1.0MIN *251JV4 191848652732
SL0761L2 500MA LOG *291SVL 198934277817   SL0761L2 900MA LOG 1.0MIN *2704YL 194994945932   SL0761L2 MCUR LIN CH1-700MA CH2-650MA *270R85 194995085521
SL0761L2 525MA LIN 1.0MIN *2787W0 196182854316   SL0761L2 910MA LIN 1.0MIN *272CTR 194995482436   SL0761L2 MCUR LIN CH1-700MA CH2-650MA 1.0MIN *270R7M 194995085392
SL0761L2 575MA LIN *250GTA 191848341711   SL0761L2 950MA LIN 0.6MIN *2633SN 193048603927   SL0761L2 MCUR LIN CH1-700MA CH2-725MA *270R86 194995085538
SL0761L2 575MA LIN 1.0MIN *251JUT 191848652602   SL0761L2 MCUR LOG CH1-700MA CH2-750MA *270R32 194995084128   SL0761L2 MCUR LIN CH1-700MA CH2-725MA 1.0MIN *270R7N 194995085385
SL0761L2 575MA LIN 10.0MIN *2823GG 196183770417   SL0761L2 MCUR LOG CH1-700MA CH2-750MA 1.0MIN *270R2J 194995083985   SL0761L2 MCUR LIN CH1-700MA CH2-750MA *270R88 194995085576
SL0761L2 575MA LOG *251JU6 191848652442   SL0761L2 MCUR LOG CH1-725MA CH2-650MA *270R33 194995084142   SL0761L2 MCUR LIN CH1-700MA CH2-750MA 1.0MIN *270R7R 194995085408
SL0761L2 575MA LOG 1.0MIN *251JWC 191848653067   SL0761L2 MCUR LOG CH1-725MA CH2-650MA 1.0MIN *270R2K 194995084029   SL0761L2 MCUR LIN CH1-725MA CH2-650MA *270R8A 194995085583
SL0761L2 580MA LIN 1.0MIN *271J2S 194995276714   SL0761L2 MCUR LOG CH1-725MA CH2-700MA *270R34 194995084197   SL0761L2 MCUR LIN CH1-725MA CH2-650MA 1.0MIN *270R7U 194995085439
SL0761L2 600MA LIN *25828M 193048047813   SL0761L2 MCUR LOG CH1-725MA CH2-700MA 1.0MIN *270R2M 194995084036   SL0761L2 MCUR LIN CH1-725MA CH2-700MA *270R8H 194995085668
SL0761L2 600MA LIN 1.0MIN *2582KX 193048050486   SL0761L2 MCUR LOG CH1-725MA CH2-750MA *270R37 194995084180   SL0761L2 MCUR LIN CH1-725MA CH2-700MA 1.0MIN *270R7V 194995085453
SL0761L2 600MA LOG *2582K9 193048050318   SL0761L2 MCUR LOG CH1-725MA CH2-750MA 1.0MIN *270R2S 194995084005   SL0761L2 MCUR LIN CH1-725MA CH2-750MA *270R8U 194995085750
SL0761L2 600MA LOG 1.0MIN *2582LA 193048050585   SL0761L2 MCUR LOG CH1-900MA CH2-875MA 1.0MIN *2704SS 194994944249   SL0761L2 MCUR LIN CH1-725MA CH2-750MA 1.0MIN *270R7X 194995085460
SL0761L2 615MA LIN 1.0MIN *271J2M 194995276653   SL0761L2 MCUR LOG CH1-700MA CH2-725MA 1.0MIN *270R2H 194995083954   SL0761L2 MCUR LIN CH1-750MA CH2-725MA *25713U 193047922388
SL0761L2 625MA LIN *25828R 193048047868   SL0761L2 MCUR LOG CH1-700MA CH2-575MA *251JUC 191848652503   SL0761L2 MCUR LIN CH1-900MA CH2-400MA 1.0MIN *270VR4 194995122271
SL0761L2 625MA LIN 1.0MIN *2582KY 193048050523   SL0761L2 MCUR LOG CH1-700MA CH2-575MA 1.0MIN *251JWJ 191848653111   SL0761L2 MCUR LOG CH1-425MA CH2-700MA *251JPM 191848651407
SL0761L2 625MA LOG *2582KC 193048050325   SL0761L2 MCUR LOG CH1-700MA CH2-650MA *270R2Y 194995084067   SL0761L2 MCUR LOG CH1-425MA CH2-700MA 1.0MIN *251JW9 191848653050
SL0761L2 625MA LOG 1.0MIN *2582LC 193048050608   SL0761L2 MCUR LOG CH1-700MA CH2-650MA 1.0MIN *270R2F 194995083961   SL0761L2 MCUR LOG CH1-575MA CH2-700MA *251JU7 191848652466
SL0761L2 650MA LIN *2582K5 193048050271   SL0761L2 MCUR LOG CH1-700MA CH2-725MA *270R31 194995084135   SL0761L2 MCUR LOG CH1-575MA CH2-700MA 1.0MIN *251JWF 191848653081
SL0761L2 650MA LIN 1.0MIN *2582L1 193048050516   SL0761L2 MCUR LOG CH1-650MA CH2-750MA *270R2X 194995084098   SL0761L2 MCUR LOG CH1-650MA CH2-700MA *270R2V 194995084050
SL0761L2 650MA LOG *2582KE 193048050332   SL0761L2 MCUR LOG CH1-650MA CH2-750MA 1.0MIN *270R95 194995085767   SL0761L2 MCUR LOG CH1-650MA CH2-700MA 1.0MIN *270R8Y 194995085743
SL0761L2 650MA LOG 1.0MIN *2582LE 193048050639   SL0761L2 MCUR LOG CH1-700MA CH2-425MA *251JU9 191848652473   SL0761L2 MCUR LOG CH1-650MA CH2-725MA *270R2W 194995084074
SL0761L2 700MA LIN *250GSM 191848341605   SL0761L2 MCUR LOG CH1-700MA CH2-425MA 1.0MIN *251JWG 191848653104   SL0761L2 MCUR LOG CH1-650MA CH2-725MA 1.0MIN *270R91 194995085774
SL0761L2 700MA LIN 0.6MIN *2594H6 193048180183   SL0761L2 700MA DTW LOG 27-50K 10-10LM *271NYH 194995316342
SL0761L2 700MA LIN 1.0MIN *251JV8 191848652763
SL0761L2 700MA LIN 10.0MIN *281XF7 196183733351
SL0761L2 700MA LOG *251JUG 191848652534
SL0761L2 700MA LOG 1.0MIN *251JWL 191848653135
View AllClose

Additional Information

Our Part No.:
BS46-SOLO761/L
Manufacturer Part No.:
SL0761L2
Brand:
Acuity eldoLED SOLOdrive
Fixture Type:
LED
Driver Type:
Constant-Current-Programmable
Input Voltage:
120-277V (Universal)
Max Output Power:
75W
Max Output Current:
1400mA
Output Current Programmable Range:
150-1400mA
Max Output Voltage:
55V
Dimming:
Analog (0-10V), LEDcode
Product Data Sheet:
See PDF Link Provided
Location Rating:
Dry/Damp
Dimensions:
16.69" L x 1.19" W x 1.06" H
UL Class:
Class 2
Features:
Side Feed
Alternative Keywords:
SL0761L1, SL0761L
Warranty:
Manufacturer's
Case Size:
10
