Description
Mean Well Constant Voltage LED Driver, 35W Max Power Output, Universal 120-277V Input, Fixed 36V Output Volts, up to 1000mA Output Current, Feet Mount
Mean Well 35 36V Constant Voltage LED Power Supply
APV LED Drivers are available in 8, 12, 16, 25 and 35 Watt models that act as a switching device to turn AC input voltage into a single-output DC voltage between 5 and 36V.
Features
- Max Power Output: 35W
- Fixed Output Voltage: 36Vdc
- Output Current Range: 0-1.0A
- Universal AC Voltage input
- Fully isolated plastic case
- Cooling by free air convection
- UL1310 Class 2 power unit
- IP 42 rating
- Suitable for LED related fixture or appliance (such as LED Decoration or Advertisement devices)
Mean Well APV-35 Models
Spec SheetsAdditional Information
Our Part No.: |
BSFM-APV-35-36 |
Manufacturer Part No.: |
APV-35-36 |
Brand: |
Mean Well |
Fixture Type: |
LED |
Driver Type: |
Constant-Voltage |
Input Voltage: |
120-277V (Universal) |
Max Output Power: |
35W |
Max Output Current: |
1000mA |
Max Output Voltage: |
36V |
Dimming: |
Analog (0-10V), PWM, Resistor |
Location Rating: |
Dry/Damp |
Dimensions: |
3.31" (L) x 2.24" (W) x 1.16 (H)" |
UL Class: |
Class 2 |
Warranty: |
Manufacturer's |
Case Size: |
10 |
