Description
Magnitude Lighting Constant Voltage LED Driver, 75W Max Power, 120V Input, Fixed 24Vdc Output, Output Current up to 3300mA, Phase Dimmable 1%-100%, NEMA 3R Junction Box
Magnitude 75W 24V Constant Voltage Dimming LED Power Supply - UL Listed
- Max 75W LED Power Supply
- Input Voltage: 120VAC, Output Voltage: 24VDC
- Current Output: up to 3.3A
- Dimming: phase-dimmable down to 1% with leading edge TRIAC dimmers
- Class 2 power supply
- UL Listed enclosure. Wiring compartment with two ½" knockouts
- E75L24DC-KO / E75L24DC are the exact same
Spec SheetsVideos
View AllClose
Additional Information
Our Part No.: |
BSF-MAG-E75L24DC |
Manufacturer Part No.: |
E75L24DC |
Brand: |
Magnitude Lighting |
Fixture Type: |
LED |
Driver Type: |
Constant-Voltage |
Input Voltage: |
120V |
Max Output Power: |
75W |
Max Output Current: |
3300mA |
Max Output Voltage: |
24V |
Dimming: |
TRIAC, Phase |
Product Data Sheet: |
See PDF Link Provided |
Location Rating: |
NEMA 3R |
Dimensions: |
6.77" L x 2.67" W x 1.30" H |
Features: |
Junction Box Enclosure, NEMA 3R |
UL Class: |
Class 2 |
Warranty: |
Manufacturer's |
Case Size: |
10 |
