Description
eldoLED PrevaLED BRICK (PLBRICK) LED modules, Street and Area Lighting, Options Select: Lumens 2700/3600, Color Temperature 3000/4000/5000/5700K, LED Array 2x2/2x6/2x8
eldoLED PrevaLED BRICK LED Module
Features
- High-powered light source
- LED module available with integrated optics
- Flexibility through 2 lumen packages, 4 CCTs, 3 array configurations
- Low profile form factor
- Fully dimmable
- Long life: up to 60,000 hours / L70
- PrevaLED BRICK Models
Available PrevaLED BRICK Modules
PLBRICK 3600L 730 2X2 J20 *2745G9 59112
PLBRICK 3600L 740 2X2 J20 *2745GA 59113
PLBRICK 3600L 750 2X2 J20 *2745GC 59114
PLBRICK 3600L 757 2X2 J20 *2745GE 59115
PLBRICK 2700L 730 2X6 J25 *2745GF 59116
PLBRICK 2700L 740 2X6 J25 *2745GG 59117
PLBRICK 2700L 750 2X6 J25 *2745GH 59118
PLBRICK 2700L 757 2X6 J25 *2745GJ 59119
PLBRICK 3600L 730 2X8 J25 *2745GK 59120
PLBRICK 3600L 740 2X8 J25 *2745GL 59121
PLBRICK 3600L 750 2X8 J25 *2745GM 59122
PLBRICK 3600L 757 2X8 J25 *2745GN 59123
Spec Sheets
Additional Information
Our Part No: |
BSF-PRV-2745xx |
Mfr Part #: |
Based On Option Selected |
Brand: |
Acuity eldoLED PrevaLED |
Fixture Type: |
LED |
Lumens: |
2700, 3600 |
Color Temperature: |
3000K, 4000K, 5000K, 5700K |
Array Configuration: |
2x2, 2x6, 2x6 |
CRI: |
70 |
Max Watts: |
47W, 62W |
Beam Angle: |
180° |
Features: |
LED engines and modules for street and area lighting |
Case Size: |
20 |
Warranty: |
Manufacturer's |
Step: |
20 |
