Description
Current Thomas Research Constant Current LED Driver, 12W Max Power Output, Universal 120-277V Input, 800mA Fixed Output Current, 8-16Vdc Output, 0-10V Dimming, IP66
Thomas Research 12W 800mA Constant Current LED Driver
- Total Max Power: 12 Watts
- Input Voltage: 120-277 VAC
- UL Dry & Damp Location Rated
- ULType HL Rated for Hazardous Locations
- IP66 Rated
- High Efficiency
- High Power Factor
- Black Magic Thermal Advantage™ Plastic Housing
- 0-10V & Resistance dimmable models include an extra two wires +Purple/-Gray on the output side. “-D” Compatible with most quality 0-10V wall dimmers
Spec Sheets
Additional Information
Our Part No.: |
BS14-LED12W-16-C0800-D |
Manufacturer Part No.: |
LED12W-16-C0800-D |
Manufacturer Material Code: |
93057463 |
Brand: |
Current - Thomas Research |
Fixture Type: |
LED |
Driver Type: |
Constant-Current |
Input Voltage: |
120-277V (Universal) |
Max Output Power: |
12W |
Max Output Current: |
800mA |
Output Current Factory Setting: |
800mA |
Max Output Voltage: |
16V |
Dimming: |
Analog (0-10V) |
Product Data Sheet: |
See PDF Link Provided |
Location Rating: |
Dry/Damp, HL |
Dimensions: |
4.04" L x 1.48" W x 0.95" H |
UL Class: |
Class 2 |
Features: |
Minimum Starting Temp: -40ºC |
Warranty: |
Manufacturer's 5 Year |
Case Size: |
10 |
