Description
Current Thomas Research Constant Current LED Driver, 9W Max Power Output, Universal 120-277V Input, 350mA Fixed Output Current, 18-36Vdc Output, 0-10V Dimming, IP66
Thomas Research Products 9W 250mA Power Supply
- Total Max Power: 9 Watts
- Input Voltage: 120-277 VAC
- UL Dry & Damp Location Rated
- IP66
- High Efficiency
- High Power Factor
- Black Magic Thermal Advantage™ Plastic Housing
- 0-10V & Resistance dimmable models include an extra two wires +Purple/-Gray on the output side. “-D” Compatible with most quality 0-10V wall dimmers
Spec Sheets
Additional Information
Our Part No.: |
BS14-LED12W-36-C0250-D |
Manufacturer Part No.: |
LED12W-36-C0250-D |
Manufacturer Material Code: |
93147686 |
Brand: |
Thomas Research - Current |
Fixture Type: |
LED |
Driver Type: |
Constant-Current |
Input Voltage: |
120-277V (Universal) |
Max Output Power: |
9W |
Max Output Current: |
250mA |
Output Current Factory Setting: |
250mA |
Max Output Voltage: |
36V |
Dimming: |
Analog (0-10V) |
Product Data Sheet: |
|
Location Rating: |
Dry/Damp |
Dimensions: |
4.04" L x 1.38" W x 0.95" H |
UL Class: |
Class 2 |
Features: |
Minimum Starting Temp: -30ºC |
Warranty: |
Manufacturer's 5 Year |
Case Size: |
10 |
