Description
Delta LNE-48V100WAAA Configurable Constant Power (Adjustable current and voltage) 100W LED Driver, 90-305Vac input, adjustable output up to 48Vdc and 2000mA output.
Delta 100W 4000mA / 24VDC Adjustable LED Driver
- Programmable, Enabling Hundreds of Configurations - potentiometers to adjust output voltage & constant current (CC) level
- Output Current Range: 1,000-2,000mA
- Output Voltage Range: 24-48Vdc in CC mode and 43-53Vdc in CV mode
- Dimming Controls: Non-Dimming
- IP65 and UL Dry Location
- High surge immunity (common mode: 6kV, differential mode: 4kV)
Additional Information
Our Part No: |
BS14-LNE-48V100WAAA |
Mfr Part #: |
LNE-48V100WAAA |
Dimensions: |
8.66" L x 2.68" W x 1.53" H |
Product Data Sheet: |
|
Features: |
Adjustable constant voltage or constant current |
Fixture Type: |
LED |
Weight: |
2.2 |
Case Size: |
10 |
Driver Type: |
Constant-Power |
Max Output Power: |
100W |
Max Output Voltage: |
48V |
Max Output Current: |
2000mA |
Input Voltage: |
Universal |
Dimming: |
Non Dimming |
UL Class: |
Class 2 |
Location Rating: |
Dry |
Warranty: |
Manufacturer's |
