Description
INVENTRONICS Constant Current LED Driver, Non Dimming, 24W Max Power Output, Universal 120-277V Input, Fixed 500mA Output Current, 29-48Vdc Output, Non-Dimming
INVENTRONICS LED Drivers 24W 500mA Constant Current
Every LED array or fixture requires a driver to provide efficient power. At BallastShop we offer a wide array drivers to meet your power output and dimming requirements of virtually any LED in the marketplace.
- Total Power: 24 Watts 500mA
- Input Voltage: 90-305 VAC
- IP20 Rated
- Class 2
- Efficiency 85%
- Operating temperature range: -20°C to 70°C
- Polycarbonate Housing
- Constant Current Output
- Active Power Factor Correction
- All-Around Protection: OVP, SCP and Open Lamp Protection
Spec Sheets
Additional Information
Our Part No.: |
BSF-LUC-024S050SSP |
Manufacturer Part No.: |
LUC-024S050SSP |
Brand: |
Inventronics |
Fixture Type: |
LED |
Driver Type: |
Constant-Current |
Input Voltage: |
120-277V (Universal) |
Max Output Power: |
24W, 25W |
Max Output Current: |
500mA |
Output Current Factory Setting: |
500mA |
Max Output Voltage: |
48V |
Dimming: |
Non Dimming |
Product Data Sheet: |
See PDF Link Provided |
Location Rating: |
Dry/Damp/Wet |
Dimensions: |
4.72" L x 1.65" W x 1.20" H |
UL Class: |
Class 2 |
Features: |
Short circuit and overload protection + Over temperature protection |
Warranty: |
Manufacturer's |
Case Size: |
10 |
