NXRCFX-UL924-UNV NX Lighting Controls (Hubbell) UL924 Automatic Load Control Relay

NX Lighting (Current / Hubbell) UL924 Emergency Lighting Load Controller, 120/277/347V Input, Single Pole Relay with Dual 0-10V, CAT5 Connection, 24V low voltage port, SpectraSync Color Tuning, Plenum rated with 1/2" nipple

NX Lighting NXRCFX-UL924-UNV (UL924) Emergency Lighting Load Control Relay

NX Emergency Lighting Load Controller, one single pole relay, one 0 - 10 dimmer, one color control channel

Features

• Automatically overrides lighting to emergency state upon loss of normal power
• Meets NFPA Article 700 requirements for emergency lighting
• Utilizes CAT5 connection to standard NX room controller for normal power sensing
• Meets NEC Article 700 requirements for emergency lighting
• Dual voltage, 120 or 277V operation
• Full range continuous dimming defaults to full ON
• Color channel defaults SpectraSync™ luminaires to full white to user selected color temperature
• Provision for remote test button or fire alarm interface
• Suitable for use in return air plenums
• Mounts directly to an external junction box through extended ½" chase nipple
• California Title 24 Compliant
• Buy American Act (BAA) Compliant

Note: NXRCFX-UL924-UNV can only be used with LVS-ERTB-PL-WH Test Switch

Electrical

• 20A, Tungsten, 120VAC Only
• Ballast: 20A Magnetic, 16A Electronic
• HP Rating: ½ HP, 250V, ¼ HP, 120V
• Motor Controller Rating: 1 H.P. Motor @12OVAC; 3/4 H.P @277VAC; 1/2H.P. @347VAC
