Description
Mean Well Constant Current LED Driver, Universal 120-277V Input, 12W Max Power Output, Fixed Output Current 700mA, 9-18Vdc Output Voltage
Mean Well 12W 700mA Constant Current LED Driver
Features
- Constant Current 700mA power supply
- Max Power 12W
- Universal AC Voltage input 120-277V
- Fully isolated plastic case
- Cooling by free air convection
- UL1310 Class 2 power unit
Spec Sheets
Additional Information
Our Part No.: |
BSF-APC-12-700 |
Manufacturer Part No.: |
APC-12-700 |
Brand: |
Mean Well |
Fixture Type: |
LED |
Driver Type: |
Constant-Current |
Input Voltage: |
120-277V (Universal) |
Max Output Power: |
12W |
Max Output Current: |
700mA |
Max Output Voltage: |
18V |
Dimming: |
Non Dimming |
Product Data Sheet: |
See PDF Link Provided |
Location Rating: |
Dry/Damp |
Dimensions: |
3.03" (L) x 1.57" (W) x 1.14" (H) |
UL Class: |
Class 2 |
Warranty: |
Manufacturer's |
Case Size: |
10 |
