Description
INVENTRONICS Constant Current LED Driver, 150w Max Power Outout, Universal 120-277V Input, Programmable 700-1050mA (factory default 700mA) Output Current, 5-214V Output ,Analog 0-10V Dimming, IP67
INVENTRONICS LED Driver 150W 700mA Constant Current - Programmable
Every LED array or fixture requires a driver to provide efficient power. At BallastShop we offer a wide array drivers to meet your power output and dimming requirements of virtually any LED in the marketplace.
- Total Power: 150 Watts with 1050mA max current output (factory set at 700mA)
- Input Voltage: 90-305 VAC
- Waterproof (IP67): Waterproof (IP67) and UL Dry / Damp / Wet Location
- TYPE HL, for use in a Class I, Division 2 hazardous (Classified) location
- Efficiency up to 92.5%
- Operating temperature range: -40°C to 65°C
- Dimming: 0-5V/0-10V/PWM/Timer Dimmable
Spec SheetsAdditional Information
Our Part No.: |
BSF-EUG-150S105DT |
Manufacturer Part No.: |
EUG-150S105DT |
Brand: |
Inventronics |
Fixture Type: |
LED |
Driver Type: |
Constant-Current-Programmable |
Input Voltage: |
120-277V (Universal) |
Max Output Power: |
150W |
Max Output Current: |
1050mA |
Output Current Factory Setting: |
700mA |
Output Current Programmable Range: |
700-1050mA |
Max Output Voltage: |
214V |
Dimming: |
Analog (0-10V), PWM, Timer |
Product Data Sheet: |
See PDF Link Provided |
Location Rating: |
Dry/Damp/Wet |
Dimensions: |
8.23" L x 2.66" W x 1.56" H |
UL Class: |
Class 1 |
Features: |
Input Surge Protection |
Warranty: |
Manufacturer's 7 Year |
Case Size: |
10 |
