Description
IOTA IIS-25-I sine wave output inverter, 25W Max Power Output, Dual 120/277V Input, 90 minutes of 120V or 277Vac (selectable via switch) output, 36" flex conduit, included indicator/test switch/face plate
IOTA IIS-25-I Emergency Micro Inverter - 25W 120/277V
IIS-25-I works in conjunction with LED, fluorescent, and incandescent lamp and fixture types and will automatically run switched, normally-on, or normally-off designated emergency fixtures.
- Pure sine wave output
- 25W max connected load
- Lamps operated: LED (per NEMA 410), Fluorescent, Incandescent
- Dual voltage 120/277Vac, 60Hz input
- Output Voltage: 120V or 277 VAC 60Hz slide switch selectable
- Operating temperature: 0°C to 50°C (68°F to 86°F)
- Replaceable and recyclable nickel-cadmium battery
- Remote mounting of emergency fixtures at distances up to 250 feet
- 36" Conduit
- Includes solid-state indicator light and single-pole test switch w/ white mounting faceplate
- Dry/Damp location rated
- UL and cUL Listed, CSA Certified
Spec SheetsAdditional Information
Our Part No: |
BS13-IIS-25-I |
Mfr Part #: |
IIS-25-I |
Manufacturer Material Code: |
*26589K |
Fixture Type: |
LED, Fluorescent, Incadescent |
Input Voltage: |
120/277V |
Max Output Power: |
25W |
Output Voltage: |
120V, 277V |
Dimensions: |
17.77" (L) x 3.00" (W) x 2.75" (H); 17.25" Mounting Center |
Product Data Sheet: |
See PDF Link Provided |
Dimming: |
Non Dimming |
Location Rating: |
Dry/Damp |
Features: |
120 or 277 VAC slide switch selectable output |
Alternative Keywords: |
No |
Warranty: |
Manufactturer's |
Case Size: |
ea |
