Description
Thomas Research Constant Current LED Driver, 30W Max Power Output, Universal 120-277V Input, Fixed 1250mA Output Current, 8-24Vdc Output Voltage, Analog 0-10V Dimming
Thomas Research Products 30W 1250mA Constant Current LED Power Supply
- Total Power: 30 Watts
- Input Voltage: 100-277 VAC
- Constant Current 1250mA Output
- 8-24Vdc Output Voltage Range
- IP66
- High Efficiency
- High Power Factor
- Black Magic Thermal Advantage™ Plastic Housing
- UL Dry & Damp Location Rated
- "-D" : 0-10V & Resistance dimmable models include an extra two wires +Purple/-Gray on the output side.
Spec SheetsAdditional Information
Our Part No.: |
BS14-LED30W-24-C1250-D |
Manufacturer Part No.: |
LED30W-24-C1250-D |
Manufacturer Material Code: |
93056446 |
Brand: |
Thomas Research - Current |
Fixture Type: |
LED |
Driver Type: |
Constant-Current |
Input Voltage: |
120-277V (Universal) |
Max Output Power: |
30W |
Max Output Current: |
1250mA |
Output Current Factory Setting: |
1250mA |
Max Output Voltage: |
24V |
Dimming: |
Analog (0-10V) |
Product Data Sheet: |
See PDF Link Provided |
Location Rating: |
Dry/Damp |
Dimensions: |
4.92" L x 1.69" W x 0.98" H |
UL Class: |
Class 2 |
Warranty: |
Manufacturer's |
Case Size: |
10 |
