Description
ERP Power + Light Constant Voltage LED Driver, 96W Max Power Output, Input Voltage 220-240V, Output Constant Voltage 12Vdc, Output Current 200-8000mA, Terminal Block Connection, Non-dimmable
ERP Power 96W 12V Constant Voltage LED Power Supply
- Power 96W AC DC Converter
- Input Voltage: 240VAC (220-240) VAC, Output Voltage: 12Vdc
- Current Output: range of .2-8A
- Class 2 power supply
- Complies with ENERGY STAR®, DLC (DesignLight Consortium®) and CA Title 24 technical requirements
- Very high power density of 24 W/in3
Spec Sheets
Additional Information
Our Part No.: |
ERP-VLM100E-12-T |
Manufacturer Part No.: |
VLM100E-12-T |
Brand: |
ERP Power |
Fixture Type: |
LED |
Product Data Sheet: |
See PDF Link Provided |
Driver Type: |
Constant-Voltage |
Input Voltage: |
220-240 |
Max Output Power: |
96W, 100W |
Max Output Current: |
8000mA |
Max Output Voltage: |
12Vdc |
Dimming: |
Analog (0-10V) |
Location Rating: |
IP20 |
Dimensions: |
7.60" L x 1.03" W x 0.78" H |
UL Class: |
Class 2 |
Features: |
"T" terminal block |
Warranty: |
Manufacturer's |
Case Size: |
10 |
